250Cd/M2 CSOT 15.6inch Digital Signage LCD Monitor MG1561B01-6 40PIN 1920x1080Pixel 12.0V

  • 1
  • 2
  • 3

Brand Name : CSOT

Model Number : MG1561B01-6

Certification : Rohs,CE,FCC

Place of Origin : China

MOQ : 10pcs

Price : Negotiation

Payment Terms : T/T,W, Western Union, MoneyGram

Supply Ability : 3000pcs per week

Delivery Time : 4-5 working day

Packaging Details : Industrial packing

Quality : Brand new Original

Package : Original industrial packing

material : glass

Brightness : 250ccd/m2

Resolution : 1920*1080pixels

contrast ratio : 3000:1

color : 16.7M

Working life : 15k hours

connector : 40P

Touch panel : without

Contact Now

250Cd/M2 CSOT 15.6inch digital signage LCD Monitor MG1561B01-6 40PIN 1920x1080Pixel 12.0V

MG1561B01-6 is a 15.6" diagonal a-Si TFT-LCD display panel product from China Star Optoelectronics Technology Co., Ltd (hereafter called CSOT), with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized by Einklcd in the following: WLED Backlight, With LED Driver, Reverse I/F, Matte . Based on its features, Einklcd recommend that this model be applied to Digital Signage etc. According to the information stored in einklcd this model mass production on Q1, 2022, Now this model is in production. We inputted this model's specification on Jan 4 2022 for the first time, and the latest update on Feb 10 2023. If you want to embed the LCM in your future product, einklcd strongly recommend that you should contact with CSOT or it's agent to learn lateast production and specification detail of MG1561B01-6. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.

Brand
CSOT
Model P/N
MG1561B01-6
Diagonal Size
15.6"
Panel Type
a-Si TFT-LCD, LCM
Resolution
1920(RGB)×1080, FHD 141PPI
Pixel Format
RGB Vertical Stripe
Active Area
344.16(W)×193.59(H) mm
Bezel Opening
-
Outline Dim.
351.86(H)×206.332(V) ×6.31(D) mm
Treatment
Antiglare (Haze 25%), Hard coating (3H)
Luminance
250 cd/m² (Typ.)
Contrast Ratio
3000:1 (Typ.) (TM)
View Direction
Symmetry
Response Time
30 (Typ.)(Tr+Td)
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Operating Mode
VA, Normally Black, Transmissive
Support Color
16.7M 72% NTSC
Light Source
WLED [9S6P] , 15K hours , With LED Driver
Weight
530g (Typ.)
Designed For
250Cd/M2 CSOT 15.6inch Digital Signage LCD Monitor MG1561B01-6 40PIN 1920x1080Pixel 12.0V
Frame Rate
60Hz
Touch Panel
Without
Interface Type
LVDS (2 ch, 8-bit) , 40 pins Connector
Power Supply
12.0V (Typ.)
Environment
Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
250Cd/M2 CSOT 15.6inch Digital Signage LCD Monitor MG1561B01-6 40PIN 1920x1080Pixel 12.0V250Cd/M2 CSOT 15.6inch Digital Signage LCD Monitor MG1561B01-6 40PIN 1920x1080Pixel 12.0V
